Our Jaguar screw air compressor full feature LS range (with Class 1 energy saving technology) offers several benefits:
- Jaguar Air Compressor All-In-One Air Solution (Full Feature)
- Class 1 Energy Saving (Permanent Magnet Motor Plus VSD)
- Stable Air Pressure, No Wastage
- Compact And Space-Saving
- Improved Reliability And Protection
- Lower Lifecycle Cost
- Environmentally Friendly
1. Jaguar Air Compressor All-In-One Air Solution (Full Feature)
- Air compressor, refrigerated air dryer and 5-stage filtration including electronic condensate drainage on each filter as well as electronic drainage on air dryer and air receiver.
- Provides clean, dry and reliable compressed air with minimal effort when installing.
- Plug-and-play design saves time and reduces errors in installation.
2. Jaguar Air Compressors Class 1 Energy Saving (Permanent Magnet Motor Plus VSD)
- Permanent Magnet Motor: Higher efficiency than standard induction motors, especially at partial loads.
- Variable Speed Drive (VSD): Adjusts motor speed to match real air demand which means no wasted energy from unloading or idling.
- Energy Class 1 Certification: Meets the highest efficiency standards, ensuring the lowest kW per m³/min of produced air.
- Can deliver up to 35% energy savings compared to fixed-speed compressors.
- Significantly reduces operating costs over the compressor’s lifetime.
3. Jaguar Air Compressors Stable Air Pressure, No Wastage
- VSD ensures tight pressure band control (±0.1 bar).
- No high-pressure margins required which means less energy wasted.
- Consistent air quality protects downstream equipment.
4. Jaguar Air Compressors Compact And Space-Saving
- Integrated refrigerated air dryer and 5-stage filtration inside one cabinet, mounted on an air receiver tank.
- Smaller footprint compared to separate compressor, plus dryer, plus filters and air receiver.
- Less piping equals fewer leaks and lower pressure drops.
5. Jaguar Air Compressors Improved Reliability And Protection
- Dry, clean air prevents water, oil and dirt from damaging tools, machines and end products.
- Integrated system ensures that both the air dryer and filters are correctly sized and matched to the air compressor’s output.
- Permanent magnet motors run cooler which reduces wear and extends the air compressor’s lifetime.
6. Jaguar Air Compressors Lower Lifecycle Cost
- Energy savings (VSD plus PM motor) are the biggest contributor.
- Reduced installation costs (no separate dryer/filters or air receiver to install).
- Lower maintenance costs due to an integrated, optimised design.
- Return on investment (ROI) is typically fast (often within 1–2 years).
7. Jaguar Air Compressors Environmentally Friendly
- Lower kWh consumption equals reduced CO₂ emissions.
- Built to comply with modern energy efficiency standards.
To summarise:
Our Jaguar screw air compressor full feature LS range is the perfect choice for the laser cutting industry, medical industry as well as any industry that relies on clean, dry and reliable compressed air.
Our Jaguar screw air compressor full feature LS range (with Class 1 energy saving technology) delivers:
- Up to 35% energy savings
- Consistently dry, clean air
- Compact, plug-and-play design
- Lower total cost of ownership
It’s the best choice for companies wanting maximum efficiency, reliability, and long-term savings.
