Can An Air Compressor Be Correctly Sized Off Pressure Alone?

To size an air compressor correctly cannot be based solely on pressure alone because pressure and flow (volume) are two different requirements, and both need to be considered to determine the correct air compressor size.

1. Why Pressure Alone Is Not Enough

• Pressure = energy (how hard the compressed air must be delivered).
• Flow (cfm or l/min) = quantity (how much compressed air per unit of time the equipment consumes).

→ An air compressor must meet both requirements at the same time. If an air compressor is only chosen by pressure it may not ever deliver enough flow / volume and the system will starve (tool slow-down, regulators drop, machine faults).

For example:
• One might have an air compressor that delivers 8 bar, but only 0.5 m³/min (17cfm).
• If the plant needs 8 bar at 1.5 m³/min (52cfm) that air compressor will constantly run, pressure will drop and tools will perform poorly.

2. Flow Demand Will Determine Capacity

The flow (compressed air consumption) of all connected equipment, plus an additional safety margin, determines how big the air compressor must be.
Each pneumatic tool or process consumes a certain volume of compressed air per minute determined in either l/min or cfm, so one must add them up to find the total requirement.

3. Pressure Determines the System Design

Pressure helps determine:
• The type of air compressor (rotary screw air compressor or reciprocating piston air compressor).
• The pressure control range.
• The air receiver tank size.
• The filter and air dryer selection.
However, it does not indicate how much compressed air is needed over time.

4. Proper Sizing Requires Both

To correctly size an air compressor, one needs:

1. 1. Operating pressure (bar or psi) → what the equipment needs.
   2. Total air flow (cfm or l/min) → total demand at that pressure.
   3. Duty cycle / usage pattern → how often the compressed air is used.
   4. Future growth margin → typically 10-20%.

5. If One Does Size by Pressure Alone

One risks:
• Undersized air compressor → pressure drops, tools underperform.
• Oversized air compressor → wasted energy and higher costs.
• Incorrect air treatment setup → moisture or oil problems.
